MC nylon was a familiar material in the electric construction.Our MARSHINE MC Nylon Wire Stringing Blocks are products that speed up the construction process, reduce cable wear, and are both high-strength and durable. This MARSHINE MC Nylon Wire Stringing Blocks plays a vital role in ensuring the safety and efficiency construction of wire cables.
Product Parameter
| Item Number | Model | Number of Sheave | Rated Load(kn) | Weight(kg) | Features |
| 10121 | SHD660 | 1 | 20 | 30 | Rubber coated aluminum sheave |
| 10122 | SHS660 | 3 | 40 | 106 | Middle: cast steel sheave with the width of 90mm Conductor: rubber coated aluminum sheave |
| 10123 | SHW660 | 5 | 60 | 150 | |
| 10124 | SHDN660 | 1 | 20 | 24 | MC nylon sheave |
| 10125 | SHSLN660 | 3 | 40 | 92 | Middle: MC nylon sheave Conductor: rubber coated aluminum sheave |
| 10126 | SHWLN660 | 5 | 60 | 120 | |
| 10127 | SHSQN660 | 3 | 40 | 76 | MC nylon sheave |
| 10128 | SHWQN660 | 5 | 60 | 110 | |
| 10129 | SHQZ660 | 7 | 80 | 268 | Middle: cast steel sheave Conductor: rubber coated aluminum sheave |
| 10130 | SHQ660A | 7 | 75 | 190 | Middle: cast steel sheave Conductor: MC nylon sheave |
Product Feature
Made of the durable MC nylon, known for its excellent mechanical properties, including the high strength, stiffness and the hardness, the MARSHINE MC nylon stringing block is designed to provide the smooth yet efficient cable movement, and reduce the friction and wear on the cables. Been designed to work with the different types of the cables and the ropes for its flexibility of use, this tool can help the users to deal with the most of the operation conditions. With its compact yet lightweight design, it is easy to transport and install in various of the locations.
Product Application
Our MARSHINE MC nylon stringing block is suitable the cable management, wire fixing, wire ducts and so on in the electrical and electronic industry, and is able to be used on the mechanical manufacturing like the pulleys, guide devices, transmission parts, etc. It is also suitable for installing the optical fiber ducts, network cable managers in the communication line and the network constructions.
Product Details
The details about the MARSHINE MC Nylon Wire Stringing Blocks.
Original Country:China.
Maximum applicable conductor: ACSR500.
Warranty:1year.
Wheel axle dimensions (outer diameter x core diameter x wheel axle width): Φ660 x Φ560 x 100mm.
Certification:ISO9001.
Customizable Pulley size: Φ660×Φ560×110(mm).
Leading Time:15-20days.
Rated Load: 20~75kn.
Net Weight: 18kg.
